Basic Info.
Power
1.5KW
Customized
Customized
Capacity
50 Sets Per Month
Key Word 1
Dryer Machine
Key Word 2
Potato Machine
Key Word 3
Vegetable Dryer Machine
Transport Package
Export Wooden Cases or Container
Specification
ce co ccc
Trademark
GMEC
Origin
Zhengzhou
HS Code
8438600000
Production Capacity
50 Sets Per Month
Product Description
Application of meat dryer machine :
Fruit: apple, mango, dragon fruit, peaches, apricots, plums, blue berry, strawberry, cherries, pineapple, kiwi fruit, etc.
Vegetable: leaf vegetable, potato, tomato, chili, red pepper, cassava, radish, garlic, ginger, peanut, yams, etc.
Herb: hemp, chrysanthemum, rose, lotus leaf, tea, ginseng, turmeric, ganoderma lucidum, etc.
Meat: cured meat, fish, sausage, preserved duck, beef, mutton, chicken, prok, etc.
Grain: rice, noodles, corn, wheat, soybeans, green beans, lentils, flower seeds, pumpkin seeds etc.
It can also dry the wood, seafood, tobacco leaves, paper buddhas and so on.
It can also used in Vegetable and fruit and so on.
Technical information of meat dryer machine:
| Model | Number of Trolley | Number of Plate | Motor | Area of the plates | Productivity (fresh) | Dimension (m) |
| WSHG-1 | 1 | 24 | 9kw | 5.76m² | 50kg/batch | 1.55*0.8*2.2 |
| WSHG-2 | 2 | 48 | 15kw | 11.52m² | 100kg/batch | 2.1*1.1*2.3 |
| WSHG-4 | 4 | 96 | 30kw | 23.04m² | 200kg/batch | 2.1*2*2.3 |
| WSHG-6 | 6 | 144 | 45kw | 34.56m² | 300kg/batch | 2.6*2.1*2.3 |
| WSHG-8 | 8 | 192 | 60kw | 46.08m² | 400kg/batch | 4.2*2.3*2.62 |
Working principle of Best Sale High Efficiency Meat Dryer/Dry Fish Processing Machinery:
The working principle of Best Sale High Efficiency Meat Dryer/Dry Fish Processing Machinery: untilize refrigerant compression through the compressor to form the high temperature and high pressure gas. The gas went into the condenser to release heat, the heat will be sent into the chamber by the circulation fan, to heat the air in the chamber( the maximum air temperature up to 75ºC). Then the air temperature rises, the moisture in the drying material will gradually evaporate, and then exhaust of the moisture by the fresh air dehumidification system, to achieve the drying effect.A. Technical service
1, We calculate the capacity and recommend the best models.
2, We supply you the professional refrigeration technical support and electronic technical support for your installation, debugging and operation.
3, We supply the spare parts and technical support in & after the warranty time.
4, We supply the training course to your workers at our factory if you need.
- After-sales service
1, Technical support for your installation, operation and maintenance.
2, One year's warranty, and you can pay for extended warranty.
3, Spare parts and technical support at most economic prices after the warranty.
